		<title>General Artwork Requirements (The Long)</title>
		<link>https://www.cews.co.za/knowledge-base/general-artwork-requirements-the-long/</link>

		<dc:creator><![CDATA[CE Web Solutions]]></dc:creator>
		<pubDate>Sun, 04 Mar 2018 21:53:35 +0000</pubDate>
				<guid isPermaLink="false">https://www.cews.co.za/?post_type=epkb_post_type_1&#038;p=24772</guid>

					<description><![CDATA[<p>1. Fonts All fonts must please be converted to Curves / paths. We can not import pdf files if fonts are still active. We don&#8217;t have the same fonts on our computers as what you use. Please always insure that this is done. You are welcome to mention the fonts you used in your order [&#8230;]</p>
<p>The post <a href="https://www.cews.co.za/knowledge-base/general-artwork-requirements-the-long/">General Artwork Requirements (The Long)</a> appeared first on <a href="https://www.cews.co.za">CE Web Solutions</a>.</p>
]]></description>
										<content:encoded><![CDATA[<div id="art_42">
<div class="Wp-Normal-P"><span class="Normal-C-C0"><strong>1. Fonts</strong><br />
</span> <span class="Normal-C-C1">All fonts must please be converted to Curves / paths. We can not import pdf files if fonts are still active. </span><span class="Normal-C-C1">We don&#8217;t have the same fonts on our computers as what you use. Please always insure that this is done. You are welcome to mention the fonts you used in your order email for reference in other projects.<br />
</span></div>
<div></div>
</div>
<div id="art_43">
<div class="Wp-Normal-P"><span class="Normal-C-C0"><strong>2. Palleted Fills / Lenses / Gradients /Symbols</strong><br />
</span> <span class="Normal-C-C1">We have noticed importing Adobe pdfs onto our runs that these objects tend to jump around or</span> l<span class="Normal-C-C1">oose some of its properties which it was design in originally thus we ask you to either convert these objects to 300dpi jpeg  / or flatten them in your</span> p<span class="Normal-C-C1">rogram.</span></div>
<div></div>
<div class="Wp-Normal-P"><span class="Normal-C-C0"><strong>3. Bitmaps</strong><br />
</span> <span class="Normal-C-C1">All Bitmaps must be converted to a 300dpi CMYK colour object  &#8211;  NO RGB BITMAPS WILL BE ACCEPTED.<br />
</span> <span class="Normal-C-C1">If a RGB bitmap goes to print and colour is not correct the client will held responsible for payment.</span></div>
</div>
<p><img loading="lazy" decoding="async" class="alignnone wp-image-24778 size-thumbnail" src="https://www.cews.co.za/wp-content/uploads/2018/03/rgb-150x150.jpg" alt="" width="150" height="150" srcset="https://www.cews.co.za/wp-content/uploads/2018/03/rgb-150x150.jpg 150w, https://www.cews.co.za/wp-content/uploads/2018/03/rgb-100x100.jpg 100w, https://www.cews.co.za/wp-content/uploads/2018/03/rgb.jpg 300w" sizes="(max-width: 150px) 100vw, 150px" />  <img loading="lazy" decoding="async" class="alignnone wp-image-24777 size-thumbnail" src="https://www.cews.co.za/wp-content/uploads/2018/03/cmyk-150x150.jpg" alt="" width="150" height="150" srcset="https://www.cews.co.za/wp-content/uploads/2018/03/cmyk-150x150.jpg 150w, https://www.cews.co.za/wp-content/uploads/2018/03/cmyk-100x100.jpg 100w, https://www.cews.co.za/wp-content/uploads/2018/03/cmyk.jpg 300w" sizes="(max-width: 150px) 100vw, 150px" /></p>
<div id="art_45">
<div class="Wp-Normal-P"><span class="Normal-C-C0"><strong>4. Files we work with</strong><br />
</span> <span class="Normal-C-C1">We work with Ai, Print ready &#8211; Pdf’s &#8211; and CMYK 300dpi Jpegs.<br />
</span>Word / Publisher / Paint  files is subject to an additional &#8220;conversion&#8221; fee<span class="Normal-C-C1"> to be quoted separately.<br />
</span></div>
</div>
<div>Please also name your files correctly (front and back).</div>
<div id="art_45">
<div class="Wp-Normal-P"><span class="Normal-C-C4">All files in email must be attachments NO jpegs inside an email message will be used for printing.<br />
</span></div>
</div>
<div id="art_46">
<div></div>
<div class="Wp-Normal-P"><span class="Normal-C-C0"><strong>5. Bleeds and sizes of Cards and Flyers</strong><br />
</span> <span class="Normal-C-C1">All business cards consist of the 3 following areas:<br />
</span> <span class="Normal-C-C5" style="color: #339966;">1. Safe typing area<br />
</span><span class="Normal-C-C5"><span style="color: #339966;">    Safe area works on 85 x 45mm  &#8211; make sure all your text mainly are inside this area.</span><br />
</span> <span class="Normal-C-C5"><br />
</span> <span class="Normal-C-C6" style="color: #ff0000;">2. Final Trimmed Size (know of final size of job)<br />
</span><span class="Normal-C-C6"><span style="color: #ff0000;">    The final cutting size of the business cards are 90mm x 50mm</span><br />
</span> <span class="Normal-C-C1"><br />
</span> <span class="Normal-C-C7">3. Bleed area (<strong><span style="color: #ff0000;">THE TOTAL SIZE ARTWORK SHOULD BE</span></strong> &amp; of which the blade cuts into)<br />
</span> <span class="Normal-C-C7">    The bleed area is 93mm x 53mm  which will include your background of card / image.</span></div>
<div></div>
<div class="Wp-Normal-P">
<div><a href="https://www.cews.co.za/wp-content/uploads/2018/04/Blank-Business-Card-v3.png" download="">Download Sample .png</a></div>
<div><a href="https://www.cews.co.za/wp-content/uploads/2018/04/Blank-Business-Card-PDF-v3.pdf" download="">Download Sample .pdf</a></div>
<p><span class="Normal-C-C1">Please see image below for correct and wrong sized cards. <strong><em>The wrong one did not leave enough bleed</em></strong>, thus if we stretch it, the wording will get cut off.<br />
</span></p>
</div>
</div>
<p><img loading="lazy" decoding="async" class="alignnone size-full wp-image-24779" src="https://www.cews.co.za/wp-content/uploads/2018/03/bcard-correct-banner.jpg" alt="" width="1024" height="400" srcset="https://www.cews.co.za/wp-content/uploads/2018/03/bcard-correct-banner.jpg 1024w, https://www.cews.co.za/wp-content/uploads/2018/03/bcard-correct-banner-300x117.jpg 300w, https://www.cews.co.za/wp-content/uploads/2018/03/bcard-correct-banner-768x300.jpg 768w, https://www.cews.co.za/wp-content/uploads/2018/03/bcard-correct-banner-510x199.jpg 510w" sizes="(max-width: 1024px) 100vw, 1024px" /></p>
<div id="art_47">
<div><strong>Other Design Sizes</strong></div>
<div>
<div id="art_50">
<div class="Wp-Normal-P"><span class="Normal-C-C1">A5 FLYER Total size &#8211; </span><span class="Normal-C-C7">including bleed: 216mm x 154mm<br />
</span> <span class="Normal-C-C6"><span style="color: #ff0000;">Final trimmed size: 210mm x  148mm</span><br />
</span> <span class="Normal-C-C5" style="color: #339966;">Safe area size: 204mm x  142mm</span></div>
</div>
<div id="art_51">
<div class="Wp-Normal-P"><span class="Normal-C-C0"><br />
</span> <span class="Normal-C-C1">A4 FLYER Total Size &#8211; </span><span class="Normal-C-C7">including bleed: 216mm x 303mm<br />
</span> <span class="Normal-C-C6"><span style="color: #ff0000;">Final trimmed size: 210mm x  297mm</span><br />
</span> <span class="Normal-C-C5" style="color: #339966;">Safe area size: 202mm x  289mm</span></div>
</div>
</div>
<div></div>
<div class="Wp-Normal-P"><span class="Normal-C-C0"><strong>6. Use of standard black and Rich Black</strong><br />
</span> <span class="Normal-C-C1"><br />
</span> <span class="Normal-C-C1">Printers prefer to use standard solid true black when printing text and other black objects. It runs on one plate and the registration is 100%<br />
</span> <span class="Normal-C-C1">accurate and crisp.<br />
</span> <span class="Normal-C-C1">But some designers tend to use the mixture of CMYK black ( also called rich black), it give a nice dark effect but is very tricky and a headache to<br />
</span> <span class="Normal-C-C1">Any machine minder.<br />
</span> <span class="Normal-C-C1">We strongly recommend not to use 100 Cyan  |  100 Magenta  |  100 Yellow | 100 Black<br />
</span> <span class="Normal-C-C1">If something goes slightly off print on 1 or 2 of the colour plates the imperfection becomes very clearly and the text show up fussy and unreadable.<br />
</span> <span class="Normal-C-C1"><br />
</span> <span class="Normal-C-C3">We DO NOT GUARANTEE RICH BLACK BUT WE DO PRINT THEM AT YOUR OWN RISK.<br />
</span> <span class="Normal-C-C1">We also recommend to use 80 Cyan | 10 Magenta | 10 Yellow and | 100 black but non of the breakdowns has ever been proven successfully.<br />
</span></div>
</div>
<div></div>
<div></div>
<div></div>
<p>The post <a href="https://www.cews.co.za/knowledge-base/general-artwork-requirements-the-long/">General Artwork Requirements (The Long)</a> appeared first on <a href="https://www.cews.co.za">CE Web Solutions</a>.</p>
